W2028P(4 Line/2 Line Alphanumeric Pager)
SPECIFICATIONS
Version 1.0
|
| Frequency Range | 138-174, 278-284, 405-480, 928-932MHz Bands, crystal or synthesized version |
| Channel Spacing | 25KHz |
| Signal Format | POCSAG |
| Data Transmission Rate | 512bps or 1200bps or 2400bps |
| Modulation System | Carrier frequency shift keying (NRZ) |
| Frequency Deviation | ±4.5KHz |
| Receiving Sensitivity | 512bps 5uV/m, 1200bps 7uV/m, 2400bps 10uV/m |
| Selectivity | 60dB ±25KHz |
| Image rejection | ≧50dB (138—480MHz); ≧40dB (928—932MHz) |
| Spurious Rejection | ≧60dB (138—284MHz); ≧50dB (405—932MHz) |
| Frequency Stability | ±10ppm(138-284 MHz), ±5ppm(406-480 MHz), ±3ppm(928-932MHz) |
| Tone Alert Output | More than 75dB(SPL) 10cm, frequency 2731Hz |
| Operating Voltage | 1.0V (min) |
| Operating Temp. Humidity | -10℃ to 40℃, 95% (at 40℃) |
| Storing Temp. Humidity | -10℃ to 70℃, 95% (at 40℃) |
|
FEATURES
|
|
|
Message storage Capacity
|
19 Personal messages, 16 Mail drop messages, each 512 ASCII, total 32Kbytes SRAM for memory storage.
|
| Address Code | 8 paging addresses, 4 address for Personal call o, rest of 4 addresses can be programmed as personal address or maildrop address |
| Display Format | 20 chars. x 4 lines + 1 line ICONS, or 20 chars x2 line+1line icon, user selectable |
| Hand programming | Available |
| Prompt icon | Some function can be disabled by CCP for easy operation |
| Time/Date Display | Real time with date displayed in 24 or 12 hours format |
| In Range Indication | If pager is within range of reception, " " will not be displayed |
| Low Voltage Alert | Display will show " " indicating low voltage |
| Backlight | Backlight can be turned on manually under dim environment |
| Message Received Time | Message receiving time is memorized and displayed together |
| Message protection | 16 messages |
| Message Deletion | Self messages can be deleted individually; self messages and mail drop can be deleted all. |
| Unread message | ICON will appear on display to remind unread message and audible alert (optional) |
| Duplicate Message | Duplicate message indication provided |
| Error Message | Error message indication provided |
| Melody Alert | 8 Musical Tones |
| Tone Alert | 4 different tone alerts, continuous audible alert (ccp selected), standard alert tone for different function call( programming selection), emergence alert with fixed alert tone and vibration |
| Tone Alert Time | 12~16 seconds |
| Vibration Alert | Build-in vibrator will be activated automatically to indicate receptions of calls |
| Silent Alert | Pager can receive message without vibration, tone alert |
| Alarm | Built-in alarm function at preset time |
| Language | Farsi, English, Spanish, French, Italian, German, Portuguese, Danish. Swedish. |
| OTA function | OTA function turns on/off self address and mail drop address |
| Battery | One "AAA" battery (1.5V) |
| Battery Life | 512dps, 2000 Hours (Alkaline battery), 1200bps, 1600 Hours (Alkaline battery) |
| Battery Back-up | 15 seconds (when the battery is replaced) |
| Weight | 135 gms. (including battery) |
| Size | (80.5L x 54.2W x 18.60H) mm without belt clip |
